Daccordi Griffe V1

Ab und an hat man im Leben richtig Glück. Dieses Gefühl hatte ich, als Thomas mich bat einen alten Stahlrahmen für ihn zu finden und mit einer SRAM eTap Schaltung aufzubauen. Dazu kam ein großzügiges Budget, das uns in die Lage versetzte einfach zu machen. Herausgekommen ist ein nur 7, 4 kg schweres Stahltorpedo.

img_0225

Daccordi Griffe V1

Das Daccordi ist heute fertig geworden und ich hatte gerade noch die Gelegenheit ein paar Photos zu machen, bevor sich Thomas damit auf und davon machte. Später mehr Details zu dem Aufbau, hier zunächst einmal ein paar Details der Fertigstellung.

Über den Daccordi Griffe Rahmen der hier verwendet wurde, hatte ich bereits geschrieben.  Das ist von der Form her ein sehr eleganter Rahmen mit Steam Punk entlehenen Muffen und vielen Pantografien, der daneben leicht und steif ist.Leider sieht er im Originalzustand aus, wie eine als Torpedo verkleidete Aubergine.

dscf3074

Die Original Torpedeo Aubergine.

Velociao in Berlin hat den Rahmen dann nach unseren Vorstellungen lackiert. Die da waren: Cinelli Laser Blau, ein wenig Rot und schöne, alte Daccordi Decals.

20161212_171452

Der Rahmen bei Velociao in Berlin.

Es war denn viel Arbeit im Detail notwendig, um eine moderne, elektronische Schaltung, dickbauchige Hochprofilfelgen und sonstiges modernes Teufelszeug an einen alten Stahlrahmen zu bekommen. Dieser Detailarbeit fiel leider auch die Gabel zum Opfer und wurde durch eine Carbongabel von Columbus mit 1 Zoll Carbonschaft ersetzt. Na gut, eigentlich fiel die Gebel meiner Unfähigkeit zum Opfer. Aber ich bin sicher, eine Carbongabel ist besser.

img_0228

Cockpit: 3T Ergonova Lenker, Ritchey carbon Vorbau, Supacaz Lenkerband und Columbus Gabel: Irgendwo kommen die 7,4 kg ja auch her.

img_0229

Specialized Ronin Sattel, BLB Notorious Satelstütze. Und ein mob Aufkleber.

img_0230

Vittoria Schlauchreifen auf Leeze Hochprofilfelgen hinter alten Decals

img_0231

Arbeit am Detail: Rote Bremszüge, rote Endkappe. RED Bremse.

img_0233

Vorne genauso, Das Steuerkopfschild rot passend eingefärbt.

img_0234

Hier kommen noch einmal die Hauptfarben – Cinelli Blau, rot und schwarz gut zur Geltung.

img_0235

Das Cockpit von oben. Columbus Tauben Kappe.

img_0237

Ich hatte etwas Sorge, dass das Schaltwerk zu bullig wirkt, ist aber nicht der Fall.

img_0238

Hier kann man noch einmal gut die aufwändigen Muffen sehen.

img_0239

RED Kurbel mit GXP ITA Lagerschalen passten problemlos in den Griffe Rahmen

img_0240

Kombi aus Muffen, Pantos und Sattelstütze: Wow.

img_0241

Noch einmal diese Steam Punk Muffen.

5 Kommentare

Eingeordnet unter 2017, Daccordi Griffe Voss, Mob

Specialized Red Hook Track

red-hook-allez-allez-749x453

via Tracko

Ein Kommentar

Eingeordnet unter 2016, Gierige Räder, Mob

Gierige Räder: GOOD AS GOLD, FANCY AS FUCK: SPECIALIZED RRD HOOK CRITERIUM LONDON

Erster Entwurf

via Cycle EXIF

specialized-rhc-london-bike-1-625x417specialized-rhc-london-bike-2-625x417specialized-rhc-london-bike-3-625x417

specialized-rhc-london-bike-4-625x417

Da fehlt definitiv eine goldene Kettenblattschraube.

specialized-rhc-london-bike-7-625x417 (1)specialized-rhc-london-bike-8-625x417specialized-rhc-london-bike-9-625x417

Zweiter Entwurf

specialized-mckenzie-sampson-rhc-1-625x417

via Cycle EXIF



Hinterlasse einen Kommentar

Eingeordnet unter 2016, Gierige Räder, Mob

Gierige Räder: Specialized Allez 40th Anniversary Edition 2014

allez 1allez 2allez 3allez 4allez 5

via Cycle Exif

auch hier:



Hinterlasse einen Kommentar

Eingeordnet unter Gierige Räder, Mob

Not all frames are created equal. A look deep inside the carbon in counterfeit bikes.

via Velonews

Words by Logan VonBokel
Photos by Brad Kaminski and Chris Case

Workbench.BK

“The speed wobbles were so awful, I had to ride the brakes down the entire mountain,” California rider Mike Parsons said, recounting his experience descending on what he believed to be a close replica of a Specialized S-Works Tarmac SL4. “I squeezed the top tube with my knees, locked my ankles against the crank arms, and held the handlebars with everything I had just to make the speed wobbles manageable, still watching my front wheel wobble left-right.”

Parsons, a triathlete and former motocross racer, purchased his frame through DHGate.com, a website with the tagline, “Buy smart. Buy direct.” It insinuates that what you’re purchasing comes direct from the brands that are listed on its website.

But that $690 “Scott Foil Premium” frameset is not made by Scott. It’s not from the same mold as Scott’s Foil. The SL4 is not a real SL4. Both are fakes that have been reverse-engineered to be aesthetically similar pseudo-copies.

VerticalStiffness.BK

The assumptions made by consumers seeking a low-cost, Chinese-made copy of a frame might be laughable to people in the industry, but many buyers have rationalized those assumptions, until they, too, experience a similar issue to what Parsons experienced.

“I can’t afford a real S-Works. The replicas are just as good.” “They’re all made in the same factory in China.” “It’s the same mold.”

At Velo, we set out to ascertain how similar these counterfeit frames were to the authentic versions. Did they qualify as “replicas” — or deathtraps?

As we have in every VeloLab test, we enlisted the help of Microbac Laboratories. We asked them to examine Parsons’ counterfeit S-Works Tarmac SL4 and compare it to the genuine article — a 58cm 2014 Specialized S-Works Tarmac SL4.

The results are clear: The counterfeit is a poorly-executed, and dangerous, replica.

The test

The counterfeit Tarmac resembles the authentic SL4. The graphics are close, and if we did not have the real SL4 on hand to compare, we would have thought the counterfeit bike had a genuine Specialized paint job. The counterfeit seatpost, too, closely resembled that of the real SL4. However, and most importantly, upon close inspection of the frames, it was clear they are not the same. They are not even close.

First, the counterfeit frame did not come from the same mold as the SL4. If it had, the two frames would have identical geometries; they do not. No tube on the counterfeit frame is the same length as the real SL4.

S-WorksFrames.BK

The weights of the two framesets — frame, fork, headset, seatpost, and seatpost collar — were comparable. The SL4 weighed in at 1,460 grams, while the counterfeit weighed in at 1,570 grams. The weight difference between the framesets alone can be considered a wash, as the counterfeit used a low-quality headset and seat collar — two components that could very easily tack on an additional 100 grams.

The construction of the headset was particularly worrisome. The genuine SL4 uses carbon cups integrated into the frame’s head tube, while the counterfeit uses alloy cups bonded into the frame. Specialized, which has its own testing facility, tested a similar counterfeit frame and found the alloy headset cups would not hold up to even the most elementary of destructive testing. It’s a claim that Velo and Microbac can confirm; the alloy cups in our counterfeit frame displayed considerable play as we secured the frame to the testing jig.

Microbac performed several tests. The first, and least destructive, was a system “stiffness” test. This was performed by vertically loading the frame and fork with 300 pounds of force at the seatpost. The results are measured in the amount of compression, or splay, that the frames demonstrated in force per inch of vertical deflection. The results showed the counterfeit to be over 11 percent less stiff than the SL4.

To some, the difference might sound negligible; however, Steve Ferry of Microbac said, “I think it is a noteworthy difference.” In this game of high performance and marginal gains, 11 percent is a substantial figure.

FrameCutting.BK

The next test required Microbac to cut the counterfeit frame and, yes, the brand-new SL4, into several pieces to measure the tensile strength of different parts of the bike. The results of this test were even more telling.

Each frame had sections cut out of the top and bottom of the top tube, as well as out of the top, bottom, left, and right of the down tube. The strength of each cutout was individually tested, and this is where the differences of the frames were magnified. The Tarmac is engineered to ride like a high-performance bike; the counterfeit is designed to simply look like a Tarmac.

The top of the down tube on the Specialized is measurably stronger than the bottom, while on the counterfeit, the top of the down tube is slightly weaker than the bottom. The top of the Tarmac’s down tube has a modulus of elasticity (a measure of a material’s resistance to deformation) greater than 40 million psi. The counterfeit has varying elasticity between 7 million and 10 million psi, at its weakest about a quarter of the modulus of elasticity (see chart).

Graph

Bike manufacturers love to advertise their high-modulus carbon fiber frames. They often claim to use higher-modulus carbon fiber than their competitors, though a frame has a variety of carbon fabric in it. A Tarmac’s highest-modulus area is the top of the down tube, and it is quite high. The counterfeit frame, despite the fact that Parsons paid for the “higher-end carbon,” apparently used no high-modulus carbon at all.

“In total, this indicates an engineered approach to tune the ride in the Specialized, and just a blunt force approach with the counterfeit,” Ferry said. “They’re just slapping stuff into the mold. If you look at thickness, yield strength, and modulus, the Specialized is much more varied [from tube to tube as well as within each tube] and there is little difference in the counterfeit.”

If it’s too good to be true …

The websites that sell the counterfeit frames appeal to the deal-savvy consumer. In the world of cycling, where exorbitant prices seem to become more commonplace by the season, the attraction is understandable. Unfortunately, the repercussions can be tragic.

“The [S-Works] frame I wanted was $3,500, and over there it was $700. I believed they were using the same molds,” Parsons said of the counterfeit frame he purchased. “There is no scenario [where] I could recommend a knockoff frame to anyone. They’re terrifying. At minimum, it will result in a terrible crash.”

The sellers, mostly from China, seem to be unconcerned with the safety of their product, or the customers who fall for the fakes. Parsons’ pleas to return the frame went unanswered. “I think they strung me along just long enough so that I couldn’t get my credit card [bank] to cancel the transaction, but this was after all the headaches just to get the bike in my hands,” Parsons said.

As with most things, if the price tag looks too good to be true, it likely is. Don’t be the sucker who falls for it.

TensileSampleHoriz.CC

Could you tell which frame was fake? Here’s a guide to the images shown above:

– Second image from the top: fake
– Third image from the top: Left is real; right is fake.
– Two head tube images: Frame on right is fake in both.
– Splintered carbon image above: fake



Hinterlasse einen Kommentar

Eingeordnet unter 2015, Ingenieur, Mob

Pedelec

Sehen immer besser aus. Dieses Jahr beim Velothon in Berlin hatte ich aufgrund des späten Lesens der Teilnahmebedingungen doch Sorgen, ob ich mit meinem Fixie überhaupt mitfahren darf. Pedelecs sind aber nicht ausgeshlossen. DS wäre doch eine hübsche Strategie für den Velothon 2013: Startblock A, Pedelec und die Profis in Grund und Boden fahren.

BMW via Bike Rumour

BMW i Pedelec E-Bike Concept Rear

Specialized via Bike Rumor

Specialized Turbo e-bike electric bicycle for Europe

Specialized Turbo e-bike electric bicycle for Europe

Specialized Turbo e-bike electric bicycle for Europe

Audi x Ducati via Bike Rumor

Audi Ducati concept e-bike electric bicycle with lightweight carbon fiber frame and wheels



Hinterlasse einen Kommentar

Eingeordnet unter 2012, Mob, Sex. Lies & Vids

Noch mehr Crossmöhren mit Scheiben

Nachdem die UCI für pro Cyclocross Wettbewerbe ihre Regeln geändert, und Scheibenbremsen zugelassen hat, kommen nun immer mehr Herstellermodelle mit Scheibenbremen in den Handel. Ich denke es ist nur noch eine Frage der Zeit, bis wir auch die ersten Straßenmodelle namhafter und voluminöser Hersteller sehen werden.

Aus einer Übersicht von Cycling Tips

Focus Mares AX 2.0 Disc, $1799

Merida Cyclo Cross 4D, $1599

Boardman CX Pro, $1,519

Specialized CruX, $2199



Hinterlasse einen Kommentar
